Explain why tempered glass is more resistant than ordinary glass?

In short (click here for detailed version)

Tempered glass is stronger than regular glass because it undergoes a specific heat treatment that makes it harder and more durable against impacts and temperature changes.

Explain why tempered glass is more resistant than ordinary glass?
In detail, for those interested!

Composition of tempered glass

Tempered glass is a highly resistant material widely used in various applications, such as smartphones, car windshields, and shower panels. Its composition differs from that of ordinary glass, giving it its unique properties. Tempered glass is mainly composed of silicon dioxide (SiO2), with the addition of small amounts of metal oxides such as alumina (Al2O3) and magnesia (MgO). This specific composition gives tempered glass its strength and resistance to impacts.

Quenching process

The glass tempering process begins by heating ordinary glass to very high temperatures, usually around 600 to 700 degrees Celsius. Once the glass is sufficiently heated, it is rapidly cooled using a blast of air or by plunging it into a bath of oil or water. This rapid cooling creates internal stresses that increase the strength of tempered glass.

This tempering process alters the molecular structure of the glass by keeping it under significant compressive stress on the surface. This compression acts as a shield in case of impact, dissipating the energy and allowing the tempered glass to better withstand mechanical stresses. However, if the tempered glass is damaged, for example by being deeply scratched, this compression can cause it to fragment into small, non-sharp pieces, unlike ordinary glass which would break into large sharp shards.

Structure and properties of tempered glass

Tempered glass is distinguished by an internal structure under tension, the result of the thermal tempering process. This particular structure makes tempered glass a material up to five times stronger than ordinary glass against impacts. In case of breakage, tempered glass breaks into small, rounded and less sharp pieces, reducing the risk of injuries considerably. Its increased resistance also makes it more resistant to temperature variations, thermal shocks, and mechanical stresses. Because of these properties, tempered glass is widely used in applications requiring high strength and enhanced safety, such as car windows, smartphone screens, and glass doors.

Comparison with ordinary glass

Tempered glass has a much higher resistance than ordinary glass due to its internal structure. Unlike ordinary glass, tempered glass undergoes a tempering process that makes it much harder and more shock-resistant. Tempered glass is about five times stronger than ordinary glass. In case of breakage, tempered glass shatters into small non-sharp pieces, which significantly reduces the risk of injuries compared to the sharp shards of ordinary glass. Tempered glass is also more resistant to scratches and bending, making it a popular choice for applications requiring greater strength and safety.

Did you know?

Good to know

Frequently Asked Questions (FAQ)

1

What are the advantages of tempered glass compared to regular glass?

Tempered glass is more resistant to impacts and scratches than ordinary glass.

2

Why is tempered glass used in smartphones and tablets?

Tempered glass is favored for its increased resistance to damage and durability, making it ideal for portable electronic devices.

3

How does the tempering process affect the strength of glass?

The rapid cooling of tempered glass creates a compressive pressure on its surface, making it harder and more resistant.

4

Is tempered glass more expensive than regular glass?

Yes, tempered glass is generally more expensive due to its specific manufacturing process.

5

How to distinguish a tempered glass from a regular glass?

Tempered glass is more resistant to shattering, and in case of breakage, it shatters into small pieces that are less dangerous than ordinary glass, which breaks into large pieces.
